FESTOOL Cordless Pendulum Jigsaw CARVEX PSC 420 EB-Basic

Description

For perfect handling at any radius.

With the FESTOOL Cordless Pendulum Jigsaw CARVEX PSC 420 EB-Basic, even tight curves feel like straight lines. With 3800 strokes per minute, the high-performance, energy-efficient EC-TEC motor gives you powerful, fast sawing progress every time. Always guaranteed: Utmost precision thanks to the specially developed hammer guide and the guide jaws featuring parallel adjustment.

They act as a third guide to keep the saw blade on track without compromise. The fact that top performance does not merely relate to sawing results is also shown by the ergonomic design of our cordless pendulum jigsaws, which enables you to work tirelessly for sustained periods.

FEATURES

Excellent behaviour in curves thanks to threefold saw blade guide and rigid lifter rod.
Simple handling thanks to the softgrip and ergonomic design.
Electronic switch-on/off on both sides, reachable in every grip position.
Fast, tool-free changing of tables, baseplates and saw blades.
Easily visible scribe mark through stroboscope light and powerful extraction.
Powerful cutting stroke for rapid working progress.
Ideal in combination with the Li-HighPower battery pack: Weighing not even 600 grams, it is both 20% lighter and 50% more compact than a 5.2 Ah standard battery pack.
The FESTOOL Cordless Pendulum Jigsaw CARVEX PSC 420 EB-Basic in a Systainer³ can also be seamlessly integrated into bott vehicle equipment for easy transportation from the workshop to the construction site.
Systainer³ products are compatible with one another and can be connected to all previous Systainer generations, mobile dust extractors and many other system accessories, such as roll boards or the mobile workshop.

APPLICATIONS

Cut-outs for sinks and kitchen hobs.
Trimming work on furniture, and kitchens, for interior fitting.
Cutting circles and curves.
Coping end strips.
Cutting workpieces to length.
Edge notching on beams.
Cutting from below.

Additional information

Battery voltage	18 V
Stroke rate	1 500 – 3 800 min⁻¹
Pendulum cover adjustment in stages	4,00
Cutting depth in wood	120,00 mm
Cutting depth in NF metals	20,00 mm
Cutting depth in steel (soft)	10,00 mm
Transport weight incl. accessories	4,06 kg
Drive type	Battery

Product Highlights

Achieve ideal results more quickly:

Works as if it had a cable even though it has none. With strong traction and triple saw blade guide for excellent curve handling.

Convenient and safe:

SoftGrip prevents slipping and the splinter guard minimises laborious reworking.

Systems get it done:

One for all – the Li-HighPower Compact battery packs in the PSC 420 and PSCB 420 can be used in all cordless devices in the same class. And vice versa.

Product Details

Optimum handling and operation

With a weight of only 2.3 kg, a slim, ergonomic design, non-slip soft-grip coating and on/off switches mounted on both sides (also centrally on stirrup handle version) for right-handed and left-handed operation.

Perfect combination of power and flexibility

The perfect combination of powerful torque and ideal curve handling. With its cutting performance matching the cabled versions, the jigsaw is long-lasting and measurably superior to other cordless saws.

Powerful

3800 strokes per minute generate considerable torque – supported by the brushless, maintenance-free EC-TEC motor.

Precision cutting along the scribe mark

The stroboscopic light brings the saw blade to a visible stop, while dust extraction and the blowing function of the CARVEX keep the view of the scribe mark free.

Perfectly straight, accurate cuts

The lifting rod guide and parallel adjustable carbide jaws act as a third saw blade guide to ensure straight precision cuts.

Accurate circular cut-outs

Even the smallest circles (radii of 34 mm to 1.5 m) are easy to produce with the core maker and compatible jigsaw blade, e.g. the S 75/4 K.

Guaranteed precision

Mitre cuts and undercuts of 0 to 45° are made with the quick-change angle table.

Changing saw blades without using tools

Adapting to the working material is worth it because the results are more accurate and the saw blades last much longer. The Festool system is therefore designed to reduce set-up times, e.g. with single-handed saw blade changing.

Sophisticated design right down to the smallest detail

The lowerable dust-extraction attachment for the CARVEX PS 420 jigsaws improves suction power and therefore your view as you cut.

Scope Of Delivery

2x Sawblades (1 x fine tooth blade, 1 x universal blade)
Splinter guard
SYSTAINER SYS 3 M 187

Product Warranty

All Festool tools carry a standard 1-year warranty. Receive an additional 2-year warranty upon tool Registration.

If you would like to return a product for a warranty claim or repair (transport for the account of customer) please email us (info@topdogtoolshop.co.za) and include your order number and details of the issues you have experienced.

Once we have this confirmation we can then arrange a drop off or collection. Please note that warranty claims are not decided on by Top Dog Tool Shop, this decision sits solely with the manufacturer.
